6-channels Relay, 6-channels DI and 2-port Ethernet Switch

WISE-7560M

6-channels Relay, 6-channels DI and 2-port Ethernet Switch

  Price:  $509.00

Features

WISE-7560M provides 6 wet contact digital input channels and 6 form A electromechanical relays. It features optical isolation for 3000 VDC of transient overvoltage protection and doesn’t have channel-to-channel isolation. Note: When inductive loads are connected to the relays, a large counter electromotive force may occur when the relay actuates because of the energy stored in the load. These flyback voltages can severely damage the relay contacts and greatly shorten the relay life. Limit these flyback voltages at your inductive load by installing a flyback diode for DC loads or a metal oxide varistor for AC loads. WISE-7560M follows IEEE 802.3af-compliant Power over Ethernet (PoE) specification. It allows receiving power from PoE enabled network by Ethernet pairs. In additional to this, WISE-7560M also has a built-in two-port Ethernet switch to implement daisy-chain topology. The cabling is much easier and total costs of cable and switch are significantly reduced.

By integrating with IF-THEN-ELSE rule engine, WISE-7560M provides powerful functions such as I/O Monitoring/Control, Counter, Timer, Schedule, E-mail sending & CGI Command sending for use in various industrial applications. WISE-7560M also supports Modbus TCP and MQTT protocols to make seamless integration with SCADA, IT and IoT (Internet of Things) system.

  • Runs on browsers, no extra software tool is required.
  • No more programming, Web pages provided for control logic editing.
  • IF-THEN-ELSE logic rules execution ability.
  • Built-in I/O (Relay: 6 Channels; DI: 6 Channels)
  • Support I/O Moniitoring/Control, Counter, Timer, Schedule, Email sending and CGI Command sending operations.
  • Modbus TCP Protocol for SCADA System Integration.
  • IEEE 802.3af-compliant Power over Ethernet (PoE).
  • 2-port Ethernet Switch for Daisy-Chain Topology.
  • MQTT Protocol for IT & IoT (Internet of Things) System Integration.

Specifications

Hardware Specifications

Analog Input

Channels

6

Contact

Wet Contact

Sink/Source (NPN/PNP)

Sink/Source

On Voltage Level

+10 VDC to +50 VDC

Off Voltage Level

+4 VDC Max.

Input Impedance

10 kΩ

Counters

Channels

6

Max. Counts

16-bit (65535)

Max. Input Frequency

50 Hz

Min. Pulse Width

10 ms

Overvoltage Protection

70 VDC

Power Relay

Channels

6

Type

Power Relay, Form A (SPST N.O.)

Contact Rating

5 A @ 250 VAC/24 VDC (Resistive Load)

Min. Contact Load

10 mA @ 5 V

Operate Time

10 ms (max.)

Release Time

5 ms (max.)

Mechanical Endurance

2 × 107 ops.

Electrical Endurance

105 ops.

Communication

Ethernet Port

2 x RJ-45, 10/100 Base-TX, Swtich Ports

PoE

Yes

Protocol

Modbus TCP, MQTT

LED Indicators

Ethernet Port

2 x RJ-45, 10/100 Base-TX, Swtich Ports

PoE

Yes

for System Running

Yes

for Ethernet Link/Act

Yes

for I/O Channel Status

Yes

for PoE Power

Yes

2-Way Isolation

I/O

2500 VDC

EMS Protection

ESD (IEC 61000-4-2)

±4 kV Contact for Each Terminal and
±8 kV Air for Random Point

EFT (IEC 61000-4-4)

±2 kV for Power Line

Surge (IEC 61000-4-5)

±2 kV for Power Line

Power

Reverse Polarity Protection

Yes

Powered from Terminal Block

12 ~ 48 VDC

Powered from PoE

Yes, IEEE 802.3af, Class1

Consumption

3.8 W (Max.)

Mechanical

Dimensions (L x W x H)

120mm x 97mm x 42mm

Installation

Wall mounting

Environment

Operating Temperature

-25 °C to +75 °C

Storage Temperature

-30 °C to +80 °C

Humidity

10 to 90% RH, non-condensing

Software Specifications

Functions

Rule Configuration Website

Access Web server on WISE controllers to edit and upload logic rules through web browser.

72 IF-THEN-ELSE Logic Rules

3 IF conditions with AND or OR operators
3 THEN actions and 3 ELSE actions

48 Internal Registers

Hold temporary variables and read/write data

24 Timers

Delay / Timing functions.

24 Schedules

Setup prescheduled routine tasks.

24 Emails

Send Email messages to pre-set Email receivers.

24 CGI Commands

Send pre-set CGI commands.

24 Recipes

Set up THEN/ELSE action groups.

8 P2P remote modules

Set up the connection information for the remote WISE modules.

Modbus TCP Protocol

Real time control and monitoring I/O channels and system status of controllers via SCADA software.

MQTT Protocol

Real time message publish/subscribe mechanism for I/O channels and system status via IT/IoT software.

IF Conditions

DI Channel

ON, OFF, ON to OFF, OFF to ON, Change

Internal Register

=, >, <, >=, <= (value)

DI Counter
DO Counter

=, >, <, >=, <= (value), Change

Timer

Timeout, Not Timeout

Schedule

In Range, Out of Range

P2P

DI, AI, DI counter, DO counter, IR

Rule Status

Enable, Disable

THEN / ELSE Actions

DO Channel

ON, OFF, Pulse Output

Internal Register

Change the value

DI Counter
DO Counter

Reset

Timer

Start, Reset

Schedule

Enable, Disable

Email
MQTT message
CGI Commands

Send

Recipe

Execute

P2P

DO(On/Off), AO, IR

Rule Status

Enable, Disable
