PoE Ethernet I/O Module with 2-port Ethernet Switch, with 12-channel Digital Input, 6-channel Digital Output (RoHS)

PET-7250A

PoE Ethernet I/O Module with 2-port Ethernet Switch, with 12-channel Digital Input, 6-channel Digital Output (RoHS)

  Price:  $419.00

Fastest Delivery: (Details) X Delivery Details
We ship via UPS and fastest delivery is with Next Day Air. UPS Next Day Air Early typically gets their product to them as early as 8am, Next Day Air gets their product typically there by 10:30am and Next Day Air Saver typically by 3pm. We ship same day for in stock items and the lead time is up to one week for out of stock items. Delivery is dependent on UPS and your shipping method.
ADD TO CART
ADD TO CART
BUY BY 1-CLICK

Features

The PET-7250A supports IEEE 802.3af Power-Over-Ethernet (Class 1) specifications. By connecting to network devices that support the IEEE 802.3af PoE standard, power can be supplied via a copper Ethernet cable. The PET-7250A includes two built-in Ethernet switch ports, which help to reduce implementation costs as there is no need to install an additional switch in order to daisy chain the ports or to extend the network via the Ethernet line.

PET-7250A provides 6 sink-type digital output channels and 12 wet contact digital input channels, each of which is able to be used as a 32-bit counter. In addition, each digital input of PET-7250A accepts either dry contact or wet contact.

  • Built-in Web Server
  • Web HMI
  • Support for both Modbus TCP and Modbus UDP Protocols
  • Communication Security
  • 2-port Ethernet Switch for Daisy-Chain Topology
  • Dual Watchdog
  • Wide Operating Temperature Range: -25 to +75°C
  • I/O Pair Connection
  • Built-in I/O
    • DI/Counter: 12 Channels
    • DO: 6 Channels

Specifications

System Specifications

Software

Built-In Web Server

Yes

Web HMI

Yes

I/O Pair Connection

Yes

Communication

Ethernet Port

2 x RJ-45, 10/100 Base-TX, Swtich Ports

PoE

Yes

Protocol

Modbus/TCP, Modbus/UDP

Security

ID, Password and IP Filter

Dual Watchdog

Yes, Module (0.8 second), Communication (Programmable)

LED Indicators

for System Running

Yes

for Ethernet Link/Act

Yes

for DI/DO status

Yes

for PoE Power

Yes

2-Way Isolation

Ethernet

-

I/O

2500 VDC

EMS Protection

ESD (IEC 61000-4-2)

±4 kV Contact for Each Terminal and ±8 kV Air for Random Point

EFT (IEC 61000-4-4)

±4 kV for Power Line

Power Requirements

Reverse Polarity Protection

Yes

Powered from Terminal Block

12 ~ 48 VDC

Powered from PoE

Yes, IEEE 802.3af, Class1-

Consumption

2.9 W (Max.)

Mechanical

Dimensions (L x W x H)

120 mm x 76 mm x 38 mm

Installation

DIN-Rail or Wall mounting

Environmental

Operating Temperature

-25 to +75°C

Storage Temperature

-30 to +80°C

Humidity

10 to 90% RH, Non-condensing

I/O Specifications

Digital Input/Counter

Channels

12

Contact

Dry +Wet Contact

Sink/Source (NPN/PNP)

Dry: Source
Wet: Sink

Wet Contact

On Voltage Level

1 VDC Max.

Off Voltage Level

+3.5 VDC ~ +50 VDC Max.

Dry Contact

On Voltage Level

Close to GND

Off Voltage Level

Open

Input Impedance

10 kΩ

Counters

Max. Count

4,294,967,285 (32 bits)

Max. Input Frequency

100 Hz

Min. Pulse Width

5 ms

Overvoltage Protection

+60 VDC

Digital Input/Counter

Channels

6

Type

Isolated Open Collector

Sink/Source (NPN/PNP)

Sink

Max. Load Current

500 mA/channel

Load Voltage

+5 VDC ~ +50 VDC

Overvoltage Protection

60 VDC

Overload Protection

1.3 A

Short-circuit Protection

Yes

Power-on Value

Yes, Programmable

Safe Value

Yes, Programmable
