IR (Infrared) Controlled 10-channel High Power Relay Module communicable over RS-232, RS-485.  Can switch up to 10 A loads.  NO/NC switches and protection circuit are provided for each channel.  Supports operating temperatures from -25 to +75°C

IR-310-RM

IR (Infrared) Controlled 10-channel High Power Relay Module communicable over RS-232, RS-485. Can switch up to 10 A loads. NO/NC switches and protection circuit are provided for each channel. Supports operating temperatures from -25 to +75°C

  Price:  $439.00

Features

The IR-310-RM is a 10-channel high power relay module designed for the power control of various appliances. The relay module can switch up to 10 A loads. There are NO/NC switches and protection circuit for each channel. The relays can be controlled independently or sequentially by serial communication with Modbus RTU protocol, as well as by wireless IR remote control. There are also a maximum of 5 interlocked relay pairs for interlocked switching. The application field can be manual/automatic power switch, light scenario control and energy conservation etc.

IR-310-RM Application

  • e-Classroom service
  • Lighting Scenario Control
  • Home and Building Automation
  • 10 channels high power relays: 10A x 4, 5A x 6
  • Supports IR commands (custom:64, built-in:32) for relay control.
  • NO & NC terminals for each channel
  • Protection circuit for each channel
  • Sequential relay control
  • Supports maximum 5 sets of interlocked relay pairs (e.g. CW/CCW motor control)
  • Power-on values and power failure memory
  • RS-232 and RS-485 serial interface
  • Supports Modbus/RTU protocol (Slave)
  • Modbus Network IDs: 1 ~ 15 (HW); 1 ~ 247 (SW)

Utility

IR utility (contains IR-310-RM utility) is the configuration tool for IR-310-RM.

  • Can get/set separate or all settings from/to IR-310-RM.
  • For relay test and relay states indication.
  • Control IR-310-RM to emit IR commands for the IR learning remote.

IR310 Utility

Specifications

Relay Output
Number of Outputs
10
Relay Types
Form C relay SPDT
Contact Rating
5A @220VAC for RL0, RL1 & RL6~RL9
10A @220VAC for RL2 ~ RL5
(Operating temperature: 25°C)
Operating Time(Max.)
10 ms for RL0,RL1 & RL6 ~ RL9,
15 ms for RL2 ~ RL5
Release Time(Max.)
5 ms for RL0, RL1 & RL6 ~ RL9
10 ms for RL2 ~ RL5
Dielectric Strength
Open Contact
750VAC for RL0, RL1 & RL6 ~ RL9
1000VAC for RL2 ~ RL5
Contact & Coil
1500VAC for RL0, RL1 & RL6 ~ RL9
2500VAC for RL2 ~ RL5
Insulation Resistance
100 M Ohm min. at 500 VDC for RL0, RL1 & RL6 ~ RL9
1000M Ohm min. at 500VDC for RL2 ~ RL5
Life TIme
Mechanical : 1 × 10^7 OPS
Electrical : 1 × 10^5 OPS
Serial Interface
COM1 RS-232 (TxD, RxD, GND)
COM2 RS-485 (DATA+, DATA-)
Format
Parity: None, Databits: 8, Stopbits: 1
Baud Rate
9600 ~ 115200 bps
Protocol Modbus/RTU (Slave)
Modbus Net ID
Hardware: 1 ~ 15; Software: 1 ~ 247
IR interface
IR input
On-board IR receiver
3.5 mm audio jack (for CA-IR-001)
IR Remote Commands
64 IR commands (#0 ~ #63) corresponding to self-defined relay states.
32 IR commands (#192 ~ #223) corresponding to built-in relay states.
LED Display
1 LED as power indication
10 LEDs as relay output indicators
Power
Power Supply
+ 12 VDC
Power Consumption
6.5W (max)
Mechanical
Dimensions(W x H x D)
220 mm x 48 mm x 113 mm
Environmental
Operating Temperature
-25 to +75°C
Storage Temperature
-30 to +80°C
Humidity
10 to 90%, non-condensing
